PR series
-
Home > English > Products > Double Universal Joint > PR series >
Double universal joint with hard treatment
- Brand Name :DJJX
- Product Model :PR-HD23-12D-79
- Product Series :PR series
- Product Brief :Can be used as a linkage, or transmission, between two intentionally misaligned shafts, rather than just as a coupling .Lawn and garden equipment, Small marine vessels,Railroad rolling stocks, conveyors and ...
Advantages of DJJX’s Universal Joints, over those of other manufacturers:
· Many sizes available
· Max. angle 90 degree
· Available in various materials
· All subcomponents very precisely machined from bar: No cheap castings or powdered metal parts, resulting in better overall and more consistent performance
· Several subtle design innovations that optimize performance and reduce cost
· Could manufacture products according to your provided drawing or samples
Variations offered by DJJX Couplings:
· Materials for midsection: 20CrTi,20Cr
· Materials for hub: 20CrMo
· Many sizes available
· Max. angle 90 degree
· Available in various materials
· All subcomponents very precisely machined from bar: No cheap castings or powdered metal parts, resulting in better overall and more consistent performance
· Several subtle design innovations that optimize performance and reduce cost
· Could manufacture products according to your provided drawing or samples
Variations offered by DJJX Couplings:
· Materials for midsection: 20CrTi,20Cr
· Materials for hub: 20CrMo
Part NO. | ¢D |
¢d (H8) |
L | L1 | L2 | L3 |
P (H8) |
K (JS9) |
T |
PR-HD13 | 13 | 6 | 49.5 | 15.5 | 9 | 4.5 | 3 | ||
PR-HD16 | 16 | 8 | 58 | 18 | 10 | 5 | 3.5 | 2 | 9 |
PR-HD20 | 20 | 10 | 67.5 | 21 | 11 | 5 | 4 | 3 | 11.4 |
PR-HD23 | 23 | 12 | 83 | 26 | 14.5 | 7 | 5 | 4 | 13.8 |
PR-HD26 | 26 | 14 | 94.5 | 29.5 | 17 | 8.5 | 5.8 | 5 | 16.3 |
PR-HD30 | 30 | 16 | 117.5 | 37 | 22 | 11 | 6.5 | 5 | 18.3 |
PR-HD32 | 32 | 18 | 129 | 40.5 | 24 | 11.75 | 7 | 6 | 20.8 |
PR-HD36 | 36 | 20 | 139 | 43.5 | 25 | 12.5 | 8 | 6 | 22.8 |
PR-HD40 | 40 | 22 | 150 | 47 | 27 | 13.5 | 9 | 6 | 24.8 |
PR-HD44 | 44 | 25 | 168 | 52.5 | 30 | 15 | 10 | 8 | 28.3 |
PR-HD50 | 50 | 30 | 195 | 61 | 35 | 17.5 | 11.5 | 8 | 33.3 |
PR-HD59 | 59 | 35 | 224 | 70 | 40 | 20 | 13 | 10 | 38.3 |
